| Spesification |
| Construction |
Made Of steel sheet, square steel pipe and steel pipe. Assembly with a system of MIG, TIG and SPOT welding process |
| Crank Mechanism |
Adjustable manually by crank torque release system (crank can be rotated continuously without damage crank screw), crank handle can be folded |
| Back raise, Knee Raise, and Hi-Low Positions |
Back rest lifting angle : 0 - 70°
Knee rest lifting angle : 0 - 45°
Hi-Low : 530 - 730 mm |
| Mattress platform |
Powder coated steel bed board with ventilated holes, easy to clean perforated with emboss style. Equipped with mattress stopper and 4(four) drip holes for infuse stand |
| Head & foot panel |
Polypropylene head & foot board, detachable & easy to clean. Equipped with bumper (with humanization design for anti collision effect), located at each corner |
| Castor |
Four castor 5” single wheel, two with brakes |
| Side guard |
Made of aluminium alloy, with colapsible system and can be folded |
| Infuse stand |
Made of stainless steel pipe, adjustable height with screw lock.Two hanger (hook), can be folded |
| Painting |
Epoxy powder coating anti bacterial grade |
| Dimension |
Overall 2160 (L) x 960 (W) x 530-730 (H) mm
Bed Board 1930 x 830 mm |
| Accessories |
- Urinal hooks |
| Net Weight |
102 KG |
